| BEF Series |  |
222Kb |
BATM's
managed Ethernet hub series allows you to expand your networking as your
needs evolve. It delivers flexible and secure LAN solutions that easily
and cost-effectively incorporate every desktop into the network. The BEF
series hubs are equipped with a variety of available user interfaces: RJ-45,
AUI, BNC, or fiber optic interfaces.
The
SNMP agent supports up to 9 hubs by means of BATView or MiniView in-band
management or GoldView™ out-of-band management software. Additionally,
the hubs provide complete front panel diagnostics via LED indicators.
 |
One SNMP agent supports up to 9 hubs |
|
Free GoldView™ management software included |
|
Remote management via SLIP |
|
Password protection for extended user and network security |
|
Optional MAC bridge module to maintain LAN interoperability |
|
Collision detection and auto-partitioning |
| Ethernet Hubs with SNMP Agent Included | ||||
| Part Number | Description | 10BaseT | 10BaseFL | |
| BEF-0809 | 8 port 10BaseT Hub with SNMP agent BNC uplink | 8 | - | |
| BEF-1609 | 16 port 10BaseT Hub with SNMP agent, BNC uplink | 16 | - | |
| BVF-0809 | 8 port 10BaseFL (VF-45) Hub with SNMP agent, BNC uplink | - | 8 | |
| BVF-1609 | 16 port 10BaseFL (VF-45) Hub with SNMP agent, BNC uplink | - | 16 | |
| Notes: | All hubs include an SNMP agent | |||
